MTA11
Cummins MTA11-G2 MTAA11-G3 Engine for Generator Set
Condition: New / Remanufactured
Leadtime: 3 days
Specification:
| Engine Model | Cummins MTA11-G2 |
| Type | 6 Cylinder, In-line, 4 Stroke |
| Displacement | 11L |
| Bore&Stroke | 125*147 mm |
| Dry Weight(include flywheel andgenerator) | 940 KG |
| Wet Weightinclude flywheel andgenerator) | 980 KG |
| Center of Gravity from Rear Face ofFlywheel Housing | 450 mm |
| Center of Gravity Above Crankshaft Centerline | 191 mm |
| Rated Output/Speed | 224KW/1500RPM |
| Standby Output/Speed | 246KW/1500RPM |
| Brake Mean Effective/Rated Output | 1651 KPa |
| Brake Mean Effective/Standby Output | 1816 KPa |
| Fuel Consumption/Rated output | 59 L/h |
| Fuel Consumption/Standby output | 57 L/h |
| Aspiration | Turbocharged, Aftercooled |
| Fuel System | PT Pump Direct Injection |
| Engine Coolant Flow | 3.8 L/s |
| Coolant Capacity, Engine Only | 12.9L |
| Oil Pan Capacity-High/Low | 34/30 L |
| Idle speed | 675-750 RPM |
| Minimum Engine Speed | 500 RPM |
| Maximum Over Speed Capability | 1725 RPM |
| Compression ratio | 16.1:1 |
| Piston Speed | 7.4 m/sec |
| Maximum Friction Power | 22.4 KW |
| Firing Order | 1-5-3-6-2-4 |
Cummins MTA11-G2 MTAA11-G3 Engine for Generator Set
Condition: New / Remanufactured
Leadtime: 3 days
Specification:
| Engine Model | Cummins MTA11-G2 |
| Type | 6 Cylinder, In-line, 4 Stroke |
| Displacement | 11L |
| Bore&Stroke | 125*147 mm |
| Dry Weight(include flywheel andgenerator) | 940 KG |
| Wet Weightinclude flywheel andgenerator) | 980 KG |
| Center of Gravity from Rear Face ofFlywheel Housing | 450 mm |
| Center of Gravity Above Crankshaft Centerline | 191 mm |
| Rated Output/Speed | 224KW/1500RPM |
| Standby Output/Speed | 246KW/1500RPM |
| Brake Mean Effective/Rated Output | 1651 KPa |
| Brake Mean Effective/Standby Output | 1816 KPa |
| Fuel Consumption/Rated output | 59 L/h |
| Fuel Consumption/Standby output | 57 L/h |
| Aspiration | Turbocharged, Aftercooled |
| Fuel System | PT Pump Direct Injection |
| Engine Coolant Flow | 3.8 L/s |
| Coolant Capacity, Engine Only | 12.9L |
| Oil Pan Capacity-High/Low | 34/30 L |
| Idle speed | 675-750 RPM |
| Minimum Engine Speed | 500 RPM |
| Maximum Over Speed Capability | 1725 RPM |
| Compression ratio | 16.1:1 |
| Piston Speed | 7.4 m/sec |
| Maximum Friction Power | 22.4 KW |
| Firing Order | 1-5-3-6-2-4 |
